CP Steel Racks (SRCP - SRCPF - SRCPFD - SRCPFK)


Email This Page Download PDF Download PDF Printable Page
CP Steel Racks (SRCP - SRCPF - SRCPFD - SRCPFK) CP Rack & Pinions
  • SRCP---SRCPF---SRCPFD---SRCPFK---Category/Asset/SRCP---SRCPF---SRCPFD---SRCPFK---Category.png
  • CP-Steel-Racks--SRCP---SRCPF---SRCPFD---SRCPFK-
  • SRCP---SRCPF---SRCPFD---SRCPFK---Category/Asset/SRCP---SRCPF---SRCPFD---SRCPFK---Category.png
  • CP-Steel-Racks--SRCP---SRCPF---SRCPFD---SRCPFK-
This is a strong rack made of Chromoly steel, treated by carburizing. Has high-strength, high wear resistance, and enables downsizing of SR racks. J Series products are also available.
1 - 25 of 40 | Results Per Page | View | Unit of Measure
1 2
Request Information Compare Items Search by Specification
Clear Filter

Module

Effective No. of Teeth

Shape

Total Length Rack (A) (in)

Total Length Rack (A) (mm)

Face Width (B) (in)

Face Width (B) (mm)

Height (C) (in)

Height (C) (mm)

Height To Pitch Line (D) (in)

Height To Pitch Line (D) (mm)

Item #

Sell Price

CAD

Module

Effective No. of Teeth

Shape

Total Length Rack (A)

Face Width (B)

Height (C)

Height To Pitch Line (D)

Internal ID

Sell Price 1 Value

SRCP2.5-100 $16.50 CAD N/A Module N/A 0.7958 Effective No. of Teeth N/A 38 Shape N/A R1 Total Length Rack (A) N/A 3.858 in98 mm Face Width (B) N/A 0.394 in10 mm Height (C) N/A 0.472 in12 mm Height To Pitch Line (D) N/A 0.441 in11.2 mm Internal ID N/A
11126 		16.5
SRCPF2.5-1000 $94.02 CAD N/A Module N/A 0.7958 Effective No. of Teeth N/A 400 Shape N/A RF Total Length Rack (A) N/A 39.370 in1000 mm Face Width (B) N/A 0.394 in10 mm Height (C) N/A 0.472 in12 mm Height To Pitch Line (D) N/A 0.441 in11.2 mm Internal ID N/A
11147 		94.02
SRCPF2.5-500 $54.84 CAD N/A Module N/A 0.7958 Effective No. of Teeth N/A 200 Shape N/A RF Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 0.394 in10 mm Height (C) N/A 0.472 in12 mm Height To Pitch Line (D) N/A 0.441 in11.2 mm Internal ID N/A
11148 		54.84
SRCPFK2.5-500J $78.97 CAD N/A Module N/A 0.7958 Effective No. of Teeth N/A 200 Shape N/A RA Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 0.394 in10 mm Height (C) N/A 0.472 in12 mm Height To Pitch Line (D) N/A 0.441 in11.2 mm Internal ID N/A
11197 		78.97
SRCP5-100 $14.71 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 18 Shape N/A R1 Total Length Rack (A) N/A 3.858 in98 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11129 		14.71
SRCPF5-1000 $122.17 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 200 Shape N/A RF Total Length Rack (A) N/A 39.370 in1000 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11157 		122.17
SRCPF5-1500 $170.73 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 300 Shape N/A RF Total Length Rack (A) N/A 59.055 in1500 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11160 		170.73
SRCPF5-2000 $230.81 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 410 Shape N/A RF Total Length Rack (A) N/A 80.709 in2050 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11162 		230.81
SRCPF5-500 $70.28 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 100 Shape N/A RF Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11164 		70.28
SRCPFD5-1000 $143.71 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 200 Shape N/A RD Total Length Rack (A) N/A 39.370 in1000 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11189 		143.71
SRCPFD5-1500 $203.41 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 300 Shape N/A RD Total Length Rack (A) N/A 59.055 in1500 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11192 		203.41
SRCPFD5-2000 $265.34 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 410 Shape N/A RD Total Length Rack (A) N/A 80.709 in2050 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11194 		265.34
SRCPFD5-500J $101.97 CAD N/A CAD Icon (for items table) Module N/A 1.5915 Effective No. of Teeth N/A 100 Shape N/A RD Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 0.591 in15 mm Height (C) N/A 0.787 in20 mm Height To Pitch Line (D) N/A 0.725 in18.41 mm Internal ID N/A
11196 		101.97
SRCP10-100 $31.42 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 8 Shape N/A R1 Total Length Rack (A) N/A 3.858 in98 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11123 		31.42
SRCPF10-1000 $259.36 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 100 Shape N/A RF Total Length Rack (A) N/A 39.370 in1000 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11131 		259.36
SRCPF10-1500 $370.36 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 150 Shape N/A RF Total Length Rack (A) N/A 59.055 in1500 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11134 		370.36
SRCPF10-2000 $503.31 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 205 Shape N/A RF Total Length Rack (A) N/A 80.709 in2050 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11136 		503.31
SRCPF10-500 $122.05 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 50 Shape N/A RF Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11138 		122.05
SRCPFD10-1000 $291.56 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 100 Shape N/A RD Total Length Rack (A) N/A 39.370 in1000 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11165 		291.56
SRCPFD10-1500 $412.23 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 150 Shape N/A RD Total Length Rack (A) N/A 59.055 in1500 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11168 		412.23
SRCPFD10-2000 $550.19 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 205 Shape N/A RD Total Length Rack (A) N/A 80.709 in2050 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11170 		550.19
SRCPFD10-500J $185.75 CAD N/A CAD Icon (for items table) Module N/A 3.1831 Effective No. of Teeth N/A 50 Shape N/A RD Total Length Rack (A) N/A 19.685 in500 mm Face Width (B) N/A 1.181 in30 mm Height (C) N/A 1.378 in35 mm Height To Pitch Line (D) N/A 1.253 in31.82 mm Internal ID N/A
11172 		185.75
SRCP15-100 $77.03 CAD N/A CAD Icon (for items table) Module N/A 4.7746 Effective No. of Teeth N/A 5 Shape N/A R1 Total Length Rack (A) N/A 4.055 in103 mm Face Width (B) N/A 1.969 in50 mm Height (C) N/A 1.969 in50 mm Height To Pitch Line (D) N/A 1.781 in45.23 mm Internal ID N/A
11125 		77.03
SRCPF15-1000 $563.81 CAD N/A CAD Icon (for items table) Module N/A 4.7746 Effective No. of Teeth N/A 67 Shape N/A RF Total Length Rack (A) N/A 39.567 in1005 mm Face Width (B) N/A 1.969 in50 mm Height (C) N/A 1.969 in50 mm Height To Pitch Line (D) N/A 1.781 in45.23 mm Internal ID N/A
11139 		563.81
SRCPF15-1500 $808.96 CAD N/A CAD Icon (for items table) Module N/A 4.7746 Effective No. of Teeth N/A 100 Shape N/A RF Total Length Rack (A) N/A 59.055 in1500 mm Face Width (B) N/A 1.969 in50 mm Height (C) N/A 1.969 in50 mm Height To Pitch Line (D) N/A 1.781 in45.23 mm Internal ID N/A
11142 		808.96
1 - 25 of 40 | Results Per Page | View | Unit of Measure
1 2
*
